WCZ-1B Proton Magnetometer
WCZ-1B proton magnetometer is a upgrade model base on WCZ-1, which has a more compact design and internal battery. Magnetic measurement precision is ±1nT and resolution reaches 0.1nT. Boasting large storage, high resolution, and flexibility, WCZ-1B can measure total field intensity, horizontal or vertical gradient component with resolution of0.1nT by altering sensor structure.
| • Mineral survey, such as iron ore, lead-zinc ore, cupper ore |
| • Mineral prospecting, mineral ore depth, orientation, and continuity, ore shape, size and scale |
| • Oil, natural gas survey, related geological structure. |
| • General survey and local survey, geological mapping |
| • Base station for aerial and marine magnetic survey |
| • Fault detection. |
| • Archaeology. |
| • Hydrogeology. |
| • Engineering survey, such as pipe finding. |
| • Monitoring earthquake auspice, volcano and other environmental disasters. |
| • Small ferrite body finding. |
| • Total magnetic field and gradient survey (horizontal and vertical gradient, special sensor is needed) |
| • Fitted for field working as well as for base station |
| • Built-in real-time clock, the data were stored with the measuring time together |
| • Interan rechargeable lithum battery as well as support external 12v car battery |
| • Latitude, longitude, elevation and time information of every measuring point are stored to compose measuring result. Timing and storing actions carry out periodically. |
| • Large screen display, English interface, can automatically show magnetic curves, easy in operation. |
| • Backlight LCD, fitted for night survey. |
| • Keyboard is of user-friendly design and supports both hands operation. |
| • Auto and manual turning support. |
| • Easy and portable, the whole system is designed with sensor-antenna pack frame and thus can be operated by one person. |
| • With RS-232C port. |
| Measuring range | 20,000 nT ~ 100,000nT |
| Accuracy | ±1nT |
| Resolution | 0.1nT |
| Gradient permitted | ≤5,000nT/m |
| Measuring speed | ≤ 2 s / reading |
| GPS Positioning accuracy | <2.5m CEP(CEP, the circular error probability, means taking the position of antenna as the center, 2.5m as its radius to draw a circle, then 50% of the results are inside the circle while 50% of the results outside it). |
| Storage | 100,000 readings |
| Keyboard input | 16 keys |
| Port | USB port |
| Power source | Internal Rechargeable battery or external 12V battery |
| Console dimension | 210mm * 85mm * 190mm |
| Weight | 2.1Kg (including battery) |
| Sensor size | φ75mm * 155mm |
| Sensor weight | 0.8 Kg |
| Working temperature | -10 ℃~+50 ℃ |
